Key Design Features
Tool-Free Assembly
- Tri-clamp connection in seconds
- No welding or threading required
- Easy disassembly for CIP/SIP
Versatile Configurations
- Two-way (on/off) standard design
- Three-way (L-port / T-port) diversion
- Pneumatic and electric actuation
Full Bore Design
- Unrestricted flow when open
- Minimal pressure drop
- Self-draining when properly mounted
Technical Specifications
| Parameter | Range / Standard |
|---|---|
| Size Range | DN15 - DN100 (1/2" - 4") |
| Body Material | Stainless Steel 304 (1.4301), 316L (1.4404) |
| Ball Material | SS304, SS316L (mirror polished) |
| Seal Materials | PTFE, EPDM, Silicone (FDA compliant) |
| Pressure Rating | PN16 (16 bar) |
| Temperature Range | -20°C to +180°C (PTFE); -20°C to +130°C (EPDM) |
| Connection Type | Tri-Clamp (Tri-Clover) ISO 2852, DIN 32676 |
| Actuation | Manual, Pneumatic, Electric |
| Configurations | 2-way, 3-way L-port, 3-way T-port |
| Certifications | FDA, 3A, CE, ISO 9001 |
Industry Applications
- Dairy Processing: Milk collection, pasteurization, yogurt production — Tri-clamp for rapid CIP cleaning
- Beverage Production: Juice, soft drink, brewery lines — Quick changeover between product runs
- Pharmaceutical: WFI distribution, formulation tanks, CIP systems — Electropolished 316L option
- Food Processing: Sauce, soup, condiment production — FDA compliant seals
- Cosmetics: Cream, lotion, shampoo manufacturing — Corrosion resistant for chemical compatibility
- Biotechnology: Media preparation, fermentation, harvesting — Sterilizable tri-clamp connections
FDA Compliant 3A Certified CE Marked ISO 9001
Need a Quick Install Ball Valve Solution?
Our sanitary valve specialists can recommend the optimal quick install ball valve configuration for your processing application. Custom sizes, materials, and actuation options available.
